Digital Hydraulic Weld Gauge 200LB With Case

Digital hydraulic gauges feature an LCD display for easier reading of weld forces. Weld force is a critical variable in the resistance welding process. This tool allows users to validate and monitor weld forces.

The gauge features a swiveling head allowing for measurement readings in confined spaces. The load cell features a concave landing pad to accommodate varying electrode nose types. Optional flat landing pad is available upon request.

• The maximum force reading is 200 lbs

• The gauge accuracy is 2%

• The gauge cannot be used during the passing of weld current

• Requires a 3/4 inch opening between electrodes

• Displays units in PSI, bar, kgf, Mpa and atm

• Includes peak hold feature to display the peak force during measurement

• Includes NIST calibration certificate

• Response time less than 500 milliseconds

• Includes protective carrying case
